This line of vertical multistage centrifugal pump features an energy-efficient design (MEI ≥ 0.7) with key technical attributes including stainless steel stamped and welded hydraulics, a cartridge mechanical seal for 20-minute maintenance, and THD thrust balancing for high-pressure stability. Ideal for reverse osmosis systems, boiler feed, high pressure washing, industrial water treatment, HVAC, and cooling applications for corrosion resistance and space-saving vertical configuration.

Size range: DN500

Pressure range: 0.8MPa to 10bar (up to 1.0 MPa) depending on model

Flow: 0.5 - 240m³/h

Head: 4 - 312m

Power: 0.37kW - 110kW

Seal: Cartridge type mechanical seal; threaded installation (20 min replacement) without removing the motor

Temperature range: -15ºc - 180ºc

Design according: CDM, CDMF, ISO9906

End connection type: Flanged, threaded/screwed suction and discharge

Inspection and test: ISO 9906

Certificates: MEI ≥ 0.7 energy efficiency index, IE3/IE4/IE5 motor efficiency compliance GB 18613-2020

Place of origin: Zhejiang, China
